Business Phone Repair Parts

"GRRRRRRRRRR"

I WAS MAD! I had just sold 3 Modkey phones for an add-on. I knew we had 30 new ones in stock. I opened the boxes to make sure everything was there... and the were NO HANDSETS in any of the 30 brand new phones! I went Berserk! I found them scratched up and broken under seats, rolling around in trunks, laying behind the shelves in vans and piled in cardboard boxes. GREAT...The only problem with these handsets was a bad $4.00 transmitter OR receiver (hardly ever both), or a bad $2 modular jack, and we'd junked all these handsets! NOW we fix 'em right there at the customer's desk!



TRANSMITTERS

Electret Transmitters:

EMS-93 (EM95 Copy)-Silver-Saltshaker: $4.35. (Mitel, TIE CX- VDS-Modkey-612, Isoetec, Vodavi, Starplus, Northern Tel & MORE). EMS-93 is the same shape as a Carbon Transmitter, but the front is Silver instead of Black or Gray plastic. You can see this thru the holes in the mic end of the handset, so you know which type of handset you've got. If you use a Carbon transmitter on a phone that needs an electret, you will get VERY high side tone. If you use a electret on a phone that needs a carbon, you will get NO transmit.

EMS-93L (EM95-A Copy-Low Output): $4.35. Use this one when the Sidetone (your voice in your own ear) sounds too hot!

EM104 Plastic version of EMS-93L Xmitter: $4.99. (In newer sets after about 1988; TIE CX-VDS-Modkey-612, Vodavi & MORE). This Low Output Electret has a circuit board, usually with a yellow dot on a light gray plastic face. These are usually dead or alive. If you have low volume, the screen (yellow dot) may be clogged with whatever, you may be able to clean it off or tear it out.

EM116 Noise Cancelling: $17.95. Fits in any Handset K-Style or G-Style!

EM1 Pencil Eraser Sized with Pins: $2.89. Toshiba, 6500, Comdial, Panasonic & Lots More!

EM9949 Capsule: $2.99. Approximately 3/8" Diameter by 3/16" Tall. For Cordless phones etc.

EM9959 Capsule: $2.99. Approximately 1/4" Diameter by 3/16" Tall. Very small with NO PINS.

High Output Electret Mics: Use these for Handsfree ICM & Speakerphones:

EM9963 High Output 2 wire Capsule: $4.59. 3/8" x 3/16" for HF ICM/SPU.

EM-44 High Output 3 wire Capsule: $4.39 3/8" x 3/8" for HF ICM/SPU.

Carbon Transmitters:

T100 Standard High Quality Carbon Xmitter: $2.89.

EM89-5 Electronic Carbon Replacement with High Quality Sound. Fixes ITT-701 Problems: $14.95.

EM117-Noise Cancelling: $27.95. Fits any Handset, K-Style or G-Style!

Dynamic Transmitters: A Dynamic Transmitter is actually a Receiver cartridge being used

as a Transmitter. Usually, the elements will be the same size for transmit and receive (2 big or

2 small cartridges). Important: Cut one side of the Varistor to use a receiver with a

Varistor as a transmitter!

MT91 DH25 sized small xmitter: $3.99. Use for Telrad, Paragon, Toshiba 5000-6000, NEC, Macrotel, Prostar & MORE! Note: Toshiba phones in the 6000 series era have a strap on the motherboard to allow you to use a carbon handset or headset in place of the original dynamic. If the handsets get mixed up, you could get really screwed up! CHECK THOSE STRAPS!

Transmitter Spacer: $ .99 to use small MT91 as Xmitter in Handset for large Xmitter.

Transmitter Adapter: $ .99 to use large R-8 or R-7 as Xmitter in our Handset shells.

MR82: DH26 Copy (NON HAC) Use it as a Xmitter or Reciever: $4.35.

R-7: $3.99. Full Sized Xmitter - Limited Supply (no longer made) ESP, GLX, GMX & SW Bell. Important: If the phone has an R-7 as the xmitter, replace it with an R-7 or you'll have low volume!!!

R-8: $3.89. Full Sized Xmitter (Receiver too!) Cut Varistor off when used as Xmitter!

Ceramic Transmitters:

CT-4: $5.99. Ceramic Transmitter (Omega IV).

CR-5: $5.99. NON HAC Receiver/Transmitter.

Ceramic Receivers:

CR-5C - HAC: $6.59. Not interchangeable with CR-5!

CR-5 - Non HAC: $5.99 Receiver/Transmitter. Note: The Walker Poet & Marathon, Executone CX use the CR5 and CR5C. They are NOT interchangeable...No way to know which one until you open it up!

Standard Large Size Receivers: Work in 1A2, 2500 Sets, K & G Style AND MORE!

R-8: $3.89. Standard HAC Receiver. (100 @ $3.10 each)

R-100: #$4.30. BEST Standard HAC Receiver (Huge HAC Coil) Limited Supply - Manufacturer Discontinued.

U-3: $ .99. USED AT&T Untested HAC Receivers (100 @ $ .60).

Varistor: $ .50. Stops clicks in Ear!

These elements are used in all kinds of phones. Most manufacturers are moving away from Carbon transmitters, since electrets require very little current. NOTE: Because there is an FET (Transistor) inside electret mics, they blow out from static electricity often (winters are worse).

Having Static Shocks? Mix a 50/50 mixture of Downey Fabric Softener and Water in a plant sprayer with a nice big trigger, and spray the carpet, chairs, etc. It lasts about 2 months, and stops problems with computers as well as phones. It's CHEAP!

Small Size Receivers:

HR-91: $3.89. DH26 size HAC Receiver with Screws-Strip wire and put under screw - (100 @ $3.10). This small unit is in NEC, TIE Paragon, Macrotel, Toshiba 5000 - 6000 - 6500 and ?, AT&T, Panasonic, Lanier and Lots More!

NOTE: There are primarily 2 sizes of Receivers. HR-91: 1 3/8" Diameter by 3/4" High and the R-8: 1 3/4" Diameter by 7/8" High.

DH-60C: $3.89. HAC Receiver with Solder Lugs.

DH-60ESA: $3.99. 300 Ohm HAC with Solder Lugs.

DH-52 & DH-26: $ .99. Use DH60 (Solder) or HR91 (Screw) Receiver Spacer to use HR-91 or DH-60 as Large Size Receiver in Handset.

NR85A: $3.99. Mini HAC Receiver (Trendline etc.) Includes Spacer to make it full size.

NR85W: $3.99. 300 Ohm Mini HAC (Trendline etc.) Does NOT include Spacer.



RF Eliminators

We have a 99% success rate! 50% of the filters we sell are for the handset cord, and...we make the only filters available specifically for handset cords, and...the only ones that work on FM! 4 frequencies are available (stop welding noise by stringing 3 frequencies together in series!).

AM RF Eliminator modular base cord: $19.95
                 modular hand-set cord: $19.95
                 hard wired: $8.95
                 1 line: $15.95

FM RF Eliminator modular base cord: $19.95
                 modular hand-set cord: $19.95
                 1 line: $15.95

CB RF Eliminator modular base cord: $19.95
                 modular hand-set cord: $19.95
                 hard wired: $ 8.95
                 1 line: $15.95

Sealing RF Eliminator hand set: $19.95
                      base cord: $19.95
                      1 line: $15.95

Be sure to read our technical bulletin on RF Elimination!



TIE WALL KITS



• Delphi 4 Ivory/Black & Delphi 6/32 Wall Kit...........$14.99
• Ultracom UAT & Businesscom+ Wall Kit................$14.99
• Modkey (60010 type) Wall Kit...............................$13.99
• Modkey (60010 type) Handset Hang-Up Clip.........$ .89
• Delphi 6 (60030) Handset Hang-up Clip..................$ 1.89
• Meritor 6 Wire, 308, 516, Econokey Wall Kit.........$22.95
• Ultracom (older 6 wire) Wall Kit (Off White)...........$13.99

NOTE: The Ultracom Wall Kit is an Off White cradle to hold the handset. This is the same cradle used on the Meritor 6 Wire (Ivory) and the 308, 516 & Econokey...cheaper but the wrong color.

Rubber Button Repair!

NEW FORMULA!! Now you have 2 days to Paint the Buttons! No more 20 minute working time. This epoxy will now last 2 days...Low Stress Formula!

Certain Phone Manufacturers have chosen to use an Ink Coating over a Non-Conductive Rubber Button, instead of a real Conductive Rubber button. This ink flakes off after a couple of years, guaranteeing that the phone will be back for refurbishing a few times over its life. This is an annuity for these manufacturers! And they do it on purpose!

• Rubber Button 2 Vial Kit: $24.95
• Rubber Button 6 Vial Kit: $59.95

  Each Vial does 5 to 20 phones! Now fix: NEC; Walker; Comdial; Executone; AT&T Cordless; Remotes; Cellular and More! Epoxy with a 2 day working time. This stuff won't fall off! You need a razor blade to get it off a button. Easy! Just Mix: Paint: and let Dry and it's fixed!

  Be sure to read our technical bulletin on Rubber Button Repair!



  Comdial Keypad Drill & Screw Kit

  This is the ONLY way to put Comdial and other (AT&T) Keypads with mushed over plastic posts back together!

  Kit comes with 100 Screws, 100 Washers, Drill Bit and Pin Vise for $19.95.
  500 Screws: $34.75
  500 Plastic (or Metal) Washers: $24.95
  Drill Bit: $1.25

  Flush Nipper: $5.95

  COMDIAL TIP:
  Bruce Clark of Commercial Phone Repair in Jacksonville, Fl, says that he's found the cause of totally dead keypads. Bruce says to WIPE the traces around the HOLD button on the PC Board. He says he's found flakes shorting the hold button, which kills all the keys!







  AND...

  If the Traces Won't Conduct: Merlin Membrane Repair Kit: $23.45 The ONLY stuff that works on mylar (Spirit) circuit boards, and works on solid boards as well! Includes double stick tape for the Merlin Membrane. One Kit does Hundreds!



  AT&T REPAIR PARTS...FIX IT YOURSELF!

  Merlin Membranes, Housings and More:

• Merlin 5 Button Membrane....................................$11.95


• Merlin 5 Button with NEW Black Upper Housing................$15.95


• Refurbished Merlin 5 Button Lower Housing...................$ 9.95


• Merlin 10 Button Membrane...................................$14.95


• Merlin 34 Button Regular Membrane...........................$19.95


• Merlin 34 Button Deluxe Membrane............................$24.95


• Merlin 5 Button Silver End Rail.............................$  .99


• Merlin 10 Button Silver End Rail............................$ 1.59


• Merlin 34 Button Silver End Rail............................$ 2.79


• Merlin 10 & 34 Button Cradle/Speaker Housing................$ 8.95


• Merlin 10 & 34 Button End Cap...............................$ 3.95


• Merlin 10 & 34 Button C-Rail................................$ 3.95


• Merlin 5 & 10 Button Volume Control.........................$ 9.95


• CLEAR Merlin 5, 10 & 34 Btn. Volume Control Plastic Arm.....$  .99


• Bag of 1051A Lamps for 1A2..................................$ 8.00


• Clear Extension Number Plastic..............................$  .29


• 6 Button 1A2 Clear Line Plastic.............................$  .99


• 2500 Set Faceplate (100 @ .99 each).........................$ 1.29


• AT&T 2600 Handset...........................................$19.95


• NEW!!...Spirit 6 Button Flex Strip..........................$29.95








• Refurbished Black Merlin Handset: $17.95
• Refurbished Amplified: $54.95
• Our NEW Merlin Stands include Desk & Wall Brackets. These stands have larger tabs to prevent breakage when dropped!
  5 Button Stand: $ 4.50
  10 & 22 Button Stand: $ 7.50







  Micropoint Repair Pen: $12.95

  Works great on solid boards, but won't stick to mylar.
  Don't use Rubber Button Repair on Traces...it won't stick!



  Executone Replacement Dial Pads:

  $9.95 Available for: Encore, Equity III-Creme Color and Encore CX-Black.



  Fix It On Site Training Video

  How can you reduce your service inventory by half? Our customers say they can fix 60% to 70% of the phones they were sending out before, after watching this tape! Many of these can be fixed right on the customers desk in just minutes! Two solid hours of opening up phones, looking for common things that go wrong, and Fixing 'Em! Covers all types of phones. No electronics training needed! Whether you've been fixing phones for 2 weeks or 20 years, you should be able to pay for this tape in a couple of hours!

  Topics covered:

• Quick check of the phone
• Finding replacement parts
• Desoldering techniques
• Checking handsets and cords
• Transmitters and receivers
• Fixing bad volume controls
• Lots and lots of TIPS!
• Replacing hookswitches
• Replacing line key switches
• Replacing chips
• Systems with paired stations
• Swapping PROMS on boards
• Refurbishing techniques
• Using correct modular plugs
• Fixing rubber buttons and keys
• Fixing buttons that are stuck or fall off
• Fixing Merlin membranes and dials
• Burnishing contacts in switches and dials
• Static electricity problems
• Reduce service calls with RJ11's

  Fix It On Site: Two solid hours of training for only $79.95. This month only: mention that you saw this add on the Internet and get $30.00 off the price of this video! Only $49.95

  NEW MATH LESSON: Check this out....

  Any Phone Repaired for $25. It's a great deal, unless you can fix the phone yourself for $10 (New Math), and avoid using the Old Math.

• Going back to the shop and returning with a
   refurbished phone or a loaner:........................$15.00


• Repair:..............................................$25.00


• Shipping there:......................................$ 3.00


• Wait 10-30 days:.....................................$ ???


• Shipping back:.......................................$ 3.00


• Yearly cost of used phones for inventory
  (or truck stock) to use as a replacement:..............$40.00



• GRAND TOTAL:.........................................$86.00



• Or if it costs you $50 for the repair:..............$111.00!



  Many of our customers are fixing 60 to 70% of the phones that they were sending in for repair! Our Training Video and Repair Parts = NEW MATH

  Phones with these Switches were Designed to go Bad and Every one will! This isn't High Tech stuff, but the manaufacturers have convinced you that it is, so you'll keep sending those phones in to be refurbished for $50+. I've been fixing these phones for less than the cost of shipping them out since 1986. I still make money charging $15 per switch + labor = $30-45 per phone, AND I'm keeping my Customer happy! If there's a maintenance contract, I make money by replacing all the switches and then hardly ever hearing from him again!



  Hookswitch: $2.99each

• Fits the following phones and more...


  TIE                              Comdial Executech
  SRX                              Goldstar
  Concord                          Bitronics
  Intertel                         Siemens
  Vodavi                           Reliant
  Telplus                          Northcom
  Premier                          Macrotel
  Telrad                           ITT 701/3100
  Kanda                            Opus
  SW Bell

  Click here for The Hookswitch Story



  ESP Hookswitch: $3.19ea.

• Fits the following phones


  Premier ESP
  SW Bell
  Intertel GX
  GLX
  GMX

  Use the Old metal bar!


• Curved Bar (Short): $ .25ea
• Long Bar (ESP): $3.00
• NOTE: Call for tip on keeping ESP switches from breaking!



  Other Hookswitches:

• Panasonic KXT 308-616-1232 Series: $11.99
• Panasonic 7000 Series: $ 4.99
• AT&T Spirit / System 75 / Partner / Legend , Optical Hookswitch: $3.49
  or: in 50 Qty AT&T @ $2.99 each
• TIE 612 / CX / VDS & Isoetec Optical: $3.49
• TIE TC/Ultracom - Complete Assemble with the Ribbon Cable, no soldering! $22.50
• Extrom / Trillium Talk-To: $14.99
• Macrotel Excel: $ 3.19
• Premier 2600 Set: $ 3.19
• Galaxy DELTA: $ 7.99
• Toshiba 5000/6000 Replacement...Works better than the original! $3.89 or: in 50 Qty: $ 2.89 each
• CHALLENGER TELECONNECT HOOKSWITCH: $12.95

  KESTER SOLDER: $1.59 Pocket tube with clip. Keep a spare around!



  BATTERIES

  Are you sending circuit boards in for a $75 repair, just because it needs a $10 Battery? Lots of systems are getting old enough to have worn out the memory batteries. If it won't hold the program...REPLACE THE BATTERY!

• TIE MODKEY / 612 & OPUS $ 15.95
• TIE CX/CK/HX/HK, Some Merlin FP1 & All MERLIN FP 2 & MERLIN 1030/3070'S:
  $ 12.95
• MERLIN+ and MERLIN Feature Pack 1 Memory: $ 9.99
• PROSTAR & MACROTEL MT16H V60R Nicad (Flat), 3 Cell - 3.6V, RELIANT 32 V60R (Stacked): $ 12.95
• INTERTEL PHOENIX 2.4V Nicad Battery, 2 Cell (Stacked) $ 9.95
• TELECONECT 7 OMEGA IV 3.6v Lithium Battery: $ 13.95
• PREMIER ESP CR14250SE 3V Lithium Battery WITH Lugs: $ 9.95
• TIE ULTRACOM EK Lithium BR2/3A 3V Battery WITHOUT Leads: $ 9.95
• TIE 416, PARAGON, UAT, Buscom+ 3V WITH Solder Lugs: $ 10.95
• TIE 416, PARAGON, UAT, Buscom+ 3V WITHOUT Lugs: $ 10.95
• Comdial 308 KSU .47F Memory Capacitor (small): $ 9.99
• Comdial 824 and ? .47F Memory Capacitor (large): $ 9.99
• Toshiba MCCU-2 2430 3V Lithium Battery W/LEADS: $ 5.35
• Trillium 612 2032 3V Lithium Battery W/LEADS: $ 5.35
• CR 2320 3V Lithium Button Battery (No Leads): $ 4.95
• Panasonic 616 & ?? 2.4V Nicad Memory Battery Pack: $ 12.95
• MERLIN TWO 3.6V Lithium Memory Battery Pack: $ 12.95



  CORDLESS PHONE BATTERIES: $6.95



• Fits many Older Phones #390-B
• Fits Panasonic Phones #391-B
• Fits Panasonic & Sony #392-B
• Fits Uniden & Cobra #392-W
• Fits Panasonic #395-B
• Fits Uniden & Cobra #395-W
• Fits AT&T #395-J



  51A LAMPS: bag of 10 @ $7.95.

  All lamps tested good, use for 1A2.



  I.C. CHIPS:

• TIE 612 KSU Station Data Chip: $3.95
• TELRAD Handset IC with Socket (10 @ $1.59ea): $1.79



  TELRAD HANDSET TRANSMITTER IC: $1.79

  Fixes No Transmit on Handset! When a Telrad (and other brands too) LCD type phone gets hit by static electricity from the mouthpiece, it often blows the 8 pin IC located near the handset jack wires on the motherboard. Stick a socket in, then put the chip in the socket and its fixed!! Chip & Socket: 10 @ 1.59 each.



  TOUCH TONE DIALS: $11.99

  Electronic for 1A2 or 2500 sets. Comes in Gray or White.



  MODULAR JACKS: $1.89

  Wired Jacks for the Handset and Base Cords. Most in stock.



  COMDIAL JACK FOR BASE CORD: $2.49

  Solders on to the board!



  LINE KEY/DIAL SWITCHES:

• Isotec (click) Line: $ .99. The #1 problem with Isoetec!
• Toshiba 3100 Line Key: $ .99. (500 @ $ .61 each)
• Iwatsu ZTD Dial Switch: $2.69.



  RELAYS:

  This relay goes bad all the time in Toxhiba MCOU cards, and Strata 6 KSU's... causes low volume and dead lines!

• Toshiba CO Line Card and TIE 416 & 616, etc. 24V (2PDT): $5.39
• Reliamt, TIE, Executone etc. 12V Relay (2PDT): $3.99
• Executone 9V (2PDT): $8.99
• SW Bell, Intertel, Toshiba HCOU 24VCO Line (1PDT): $3.99
• TIE Ultracom Displayphone Relay: $7.99. Static on Handset & Speakerphone.



  616-W Modular Handset Jack: $1.89

  This jack is used in 98% of the Handsets! If the phone is a wall phone, the little plastic plug retainers break when the handset is dropped - so the cord won't stay in. It's also often the cause of static! Gotta have 'em!



  616 & 623 Modular Jacks: $1.89

  We have most of the modular jacks used for handsets and base cords in the phone. You'll need to tell us the 616 or 623 number / letter on the jack. For solder type jacks, call us and we'll fax you pictures of the jacks.





  TRANSFORMERS:

• These burn out ALL the time! The #1 cause of dead Toshiba phones! Use the 600/600 to replace a 600/75, it works fine!!


  Toshiba 600/9600: (100 Qty. @ $5.99 ea.)                 $7.99
  Toshiba 600/600:                                         $8.99



• Causes Brrrrrr Rrrrrrr Rrrrrrr sound when called on HF ICM!


  TIE Modkey:                                              $7.99
  TIE 612:                                                 $7.99
  Northcom 1A3:                                            $7.99



• The Pins Break all the time...There are 3 of these in a phone!


  Northcom 1648 ED3305:                                    $9.99
  SW Bell, Intertel & ESP "Blue Donut" Torrid Coil:        $6.99



• Often Breaks when Dropped!


  Extrom / Trillium Talk-To 40295 Transformer:             $9.99



• Really Breaks A Lot!


  Extrom / Trillium Panther 40449 Transformer:             $9.99



630-980-7710

Copyright © 2003 Mike Sandman Enterprises
